Product No.:
TOW1G.DA
Power Supply:
AC/DC 24 V (±10 %)
Accuracy:
± 0.2 °C between 0 °C to +50 °C
IP Rating:
IP65 to IEC60529
Measuring Range:
−40 °C to +60 °C (default), Free selectable via NFC −40 °C to +135 °C
Product Dimensions:
78 mm × 58 mm × 47 mm
Output:
0–10 V
Measuring Element:
Outside the housing
You do not have permission to view the prices

Description
The TOW1-Series (T) is designed to measure temperature in outdoor areas, plant rooms, cold stores,greenhouses, production plants and warehouses.
In accordance with RESET® and WELL Building Standard™ Reading.
Cover/bottom housing connected with magnets and two screws.
Parameter settings via NFC technology.
The temperature sensor output is active.
Use
Compatible to all common HVAC DDC and Analog Controls systems, with/without Building Automation System.
Used in all common HVAC applications.
Used in Commercial and Industrial Buildings.
Features
Sensor with active output.
Sensor outputs 0–10 V or 4–20 mA.
Reading/parameter settings via NFC technology.
Professional and practical product design.
Cover/bottom housing connected with magnets and screws.
Firmware updates via service connector.
Easy to use, install and maintain.
Download
Download Datasheet GR AP PM DS403en TOW1 T V26_1
